AG NEOVO LCD/LED TX-22 Touch BLACK Glass+++
|
|
AG NEOVO LCD/LED TX-22 Touch BLACK Glass+++
-
Skærmstørrelse
21.5"
-
Opløsning
1920 x 1080
-
HD
Fuld HD
-
USB-C
0
-
DVI
1
-
DP
0
-
HDMI
0
-
VGA
1
-
Berøringsskærm
Ja
-
Højttalere
Nej
-
3D
Nej
-
Skærmform
Flad
-
Højdejustering
Nej
-
Drejbar
Nej
-
Pivot
Nej
-
Usage
Personal display
|
Beskrivelse
Specifikationer
TX-22
Featuring an LED-backlit IPS panel, the TX-22 offers more than just full HD 1920 x 1080 resolution. Consistent and accurate colour is discernible from all viewing angles. Projected capacitive touch technology enables users to navigate the display with ease and precision. Its tilting flexibility ranging from –5 to 90 degrees ensures user comfort and ergonomically friendly for public and interactive environments. Glass overlay brings such benefits as ease of cleaning and resistance against bacteria/dust. Durable metal housing and rugged base design guarantee stability as well as strength.
Precise And Smooth Touch Experience
The TX-22 is built on innovative projected capacitive touch technology that ensures accurate and instant touch response.
10-point Touch Capability
Supported under Microsoft® 7 and 8, the TX-22 comes with 10-point touch capability that allows users to engage in more creative and exciting interactive applications.
Sophisticated Design
With a true flat surface and edge-to-edge glass overlay, the TX-22 offers an invitingly modern appeal that fits the professional environment.
Maximise User Comfort
With an ergonomically-friendly design, the TX-22 provides more viewing angles with a wide range tilt flexibility from –5º - 90º.
IPS
IPS panel technology ensures consistent and accurate colour from all viewing angles.
IP65 Rating
With the front panel rated IP65, the TX-22 is effectively protected against the ingress of dust and splashing liquid, a common risk in such demanding public places as hospitals, museums and school labs.
Features
- Incorporate Projected Capacitive Touch Technology
- 10-point touch capability for systems with Microsoft® Windows® 7 and 8 support plug and play
- 5-point touch capability for systems with Linux, Android 2.1 upward support by driver, 10-point
- touch capability for systems with Android 4.0 support by driver
- Single touch point capability for systems with Windows® VISTA, XP, 2000, Win CE, XP
- Embedded, Apple® Mac OS support by driver
- IPS panel ensures consistent and accurate colour from all viewing angles
- Front-sided IP65 rating protects screens from splashing liquid and dust
- 1920 x 1080 Full HD resolution
- Flush touch screen makes surface neat and clean
- Tilt capacity from –5º to 90º
- Dual inputs: VGA and DVI
- RJ11 for remote control
- HID compliant for easy integration
- Durable metal housing
- Rugged base design for superb stability
- Touch method: fingers or magnetic ball pens
- Lockable OSD setting
Display |
|---|
| Skærm diagonal | 54,6 cm (21.5") |
| Skærmopløsning | 1920 x 1080 pixel |
| Skærmteknologi | LCD |
| Berøringsskærm | Ja |
| HD-type | Fuld HD |
| Berøringsskærmstype | Bordplade |
| Berøringsskærm teknologi | Projekteret kapacitivt systemet |
| Berøringsteknologi | Multi-touch |
| Responstid | 7 ms |
| Skærm form | Flad |
| Kontrastforhold (typisk) | 1000:1 |
| Maksimal opdateringshastighed | 60 Hz |
| Synsvinkel, horisontal | 178° |
| Synsvinkel, vertikal | 178° |
| Vis antal farver | 16,78 millioner farver |
| Pixel pitch | 0,248 x 0,248 mm |
| Digital horisontal frekvens | 31,47 - 82,3 kHz |
| Digital vertikal frekvens | 56 - 75 Hz |
| Skærm diagonal (metrisk) | 54,61 cm |
| Skærmens lysstyrke | 250 cd/m² |
| LED-baggrundsbelysning | Ja |
Præstation |
|---|
| NVIDIA G-SYNC | Nej |
| AMD FreeSync | Nej |
| Understøttede Windows-operativsystemer | Windows 7, Windows 8 x64, Windows 8.1 |
Multimedie |
|---|
| Indbygget kamera | Nej |
| Indbygget mikrofon | Nej |
Design |
|---|
| Produktfarve | Sort |
| Certificering | FCC, CB, CE, BSMI |
Porte & Grænseflader |
|---|
| USB upstream port type | USB Type-B |
| Antal upstream-porte | 1 |
| Antal VGA-porte (D-sub) | 1 |
| DVI-port | Ja |
| Antal DVI-D-porte | 1 |
Ergonomisk |
|---|
| Panel montering grænseflade | 100 x 100 mm |
| Kan monteres på væggen | Ja |
| Hældningsvinkelområde | -5 - 90° |
Strømstyring |
|---|
| Strømforbrug (typisk) | 27 W |
| Strømforbrug (standby) | 2 W |
| Strømforbrug (slukket) | 1 W |
| Vekselstrømsindgangsspænding | 100 - 240 V |
| Vekselstrømsindgangsfrekvens | 50 - 60 Hz |
| Udgangsspænding for vekselstrømsadapter | 12 V |
| Strømforsyningstype | Vekselstrøm/jævnstrøm |
Driftsbetingelser |
|---|
| Driftstemperatur (T-T) | 0 - 40 °C |
| Opbevaringstemperatur (T-T) | -20 - 60 °C |
| Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
| Relativ luftfugtighed ved opbevaring (H-H) | 20 - 80% |
Emballage indhold |
|---|
| Kabler inkluderet | Vekselstrøm, DVI, USB, VGA |
| Hurtig start guide | Ja |
Vægt & størrelser |
|---|
| Bredde (med stativ) | 528 mm |
| Dybde (med stativ) | 214 mm |
| Højde (med stativ) | 347 mm |
| Vægt (med stativ) | 6,7 kg |
Emballeringsdata |
|---|
| Pakkevægt | 9,8 kg |
Andre funktioner |
|---|
| AC-adapter inkluderet | Ja |
| Dimensioner (BxDxH) med stativ | 528 x 214 x 347 mm |
